Leica ASP300

4.7.2. Access control

The Leica ASP300 may be configured to allow two levels of user ac-

cess.

Operator access level:

• Operators may run programs and view results. On this level, the OP-

ERATOR symbol is displayed in the upper right corner of the touch

screen.

Supervisor access level:

• Supervisors may perform all Operator functions, and additionally cre-

ate programs and perform the instrument sit-up functions.

• To access Supervisor level, press SUPERVISOR, enter the required

password and confirm. The SUPERVISOR symbol will then be dis-

played instead of the OPERATOR symbol and all enabled buttons will

be surrounded by a black border instead of a blue one.

Lock feature against unauthorized use

• The Leica ASP300 provides a feature called "Lock" to prevent ac-

cess to any operations of the Leica ASP300 to unauthorised users.

• The ‘Lock’ mode and the corresponding ‘Lock’ password are config-

ured from the SYSTEM SETUP menu.

4. Setting up the instrument

‘Operator’ symbol

‘Supervisor’ symbol

→
